S430 Series

Specification/Model

S1722

S1730

S1740

S1760

S1790

Swing Over Bed

430 mm

Swing Over Cross Slide

240 mm

Center Height

215 mm

Distance Between Centers

560mm

760mm

1000mm

1500mm

2200mm

Swing Over Gap

650 mm

Width of Bed

300 mm

Spindle Nose

ASA D1-6/D1-8 (Opt.)

Spindle Bore

58mm / 80mm (Opt.)

Taper of Spindle Bore

MT6/MT7 Opt.

Range of Spindle Speed

20~2000 rpm (12 steps)-spindle bore: 58mm /

40~2000 rpm (12 steps) spindle bore: 80mm

Inch Threads Range

4~ 56 tpi

Metric Threads Range

P 0.5~P 7

Longitudinal Feeds Range

0.05-0.82mm

Cross Feeds Range

0.02-0.4mm

Leadscrew Diameter

35mm

Leadscrew Pitch

4 TPI or 6mm

Taper of Tail Center

MT4

Tail Spindle Travel

150mm

Tail Spindle Diameter

58mm

Main Drive Motor

5HP (3.75KW) / 7.5HP (5.625KW) (Opt.)

Coolant Pump

1/8 HP (0.1KW)

Compound Rest Travel

125mm

Cross Slide Travel

245mm

Machine Dimensions (cm)

165x81x119

189x81x119

215x81x119

265x81x119

342x81x119

Packing Dimension (cm)

182x95x162

198 x95x162

223 x95x162

279 x95x162

361 x95x162

Net Weight

1500

1680

1760

2050

2405

Gross Weight

1600

1780

1860

2200

2555
